D80-2V - 2 Axis Digital Readout (LCD)

Features :

1) 7’’ true color LCD screen .

2 Machining drawing previwing .

3)Saving machining drawings .

4)Displaying the tools real-time position .

5)Quick “help” button .

6)Custom shortcut keys .

 Note: Below is for specification details only. There various axis avaliable



Technical Parameters :

Volatge range	AC80V-260V / 50HZ-60HZ
Power dissipation	15W
Working temperature	-10℃-60℃
Coordinates	2/3/4 or 5 axis
Times  frequency	4X
Input signal	5V TTL / 5V EIA-422-A
Input  frequency	≤4MHZ
Operating keypad	Mechanical keypad
Resolution	0.1μm,0.2μm,0.5μm,1μm,5μm,10μm,50μm

Function list :

l  Zeroing ,date recovery

l  Input coordinates

l  Metric / British units

l  Power off memory

l  Encoder selection

l  Resolution setting

l  Linear compensation

l  Counting direction setting

l  ABS/INC coordinate

l  REF

l  Calculator

l  Non-linear compensation

l  1/2 function

l  Sleeping function

l  PLD function

l  Tools offsets

l  PCD function

l  Simple R function

l  Smooth R function





l  Rectangle Chambering function

l  Taper measuring

l  Radius / Diameters conversion

l  Y + Z function

l  Digits flitering function

l  Perview drawings

l  Tool position displaying

l  Axes summing

l  EDM (optional )

l  Rotational Speed Measurement / RPM (optional )

l  RS232  port (optional )

l  Linear measuring basing rotary encoder  (optional )

This Package included the following:

1x D80-2V - 2 Axis Digital Readout (LCD)
