Switching Power Supply - 5V 10A 50W

5V 10A 50W Power Supply

Specifications:

AC Input: 110/220V ±15%

DC Output: 5V 10A

Material: Alloy

The Efficiency: 90 (%)

Modulation Mode: Pulse width modulation (PWM)

Transistor Connected Manner: Full bridge type

AC Input Voltage Range: 85-264V AC, 47-63Hz

Input Current: 0.2A/ 110V, 0.1A/ 230V

AC Inrush Current: Cold-start current 20A/ 115V, 40A/ 230V

Leakage Current: ＜1mA/ 240V AC

DC Adjustable Range: ±10% rated output voltage

Over Load Protection: 105-150% hiccup mode,auto-recovery

Over Voltage Protection: 115-135% Cut off the output,auto-recovery

Setup Rise Hold Up Time: 200ms 50ms 20ms

Withstand Voltage: I/P-O/P:1.5KvAC 1 mintute, I/P-FG:1.5KvAC 1 mintute, I/P-FG:0.5KvAC 1 mintute

Working Temperature: -10℃～＋60℃, 20%～90%RH

Connection Tips:

L,N: AC INPUT

〨: EARTH

-V: DC OUTPUT (the negative pole)

+V: DC OUTPUT (the positive pole)

Package Included:

1 x LED Driver Power Supply Transformer Adapter
