UCFL201 - 12mm Pillow Casted Metal Bearing Block
UCFL201 - 12mm Pillow Casted Metal Bearing Block
A UCFL flanged cast-metal bearing unit for a matching round shaft. This draft keeps the exact bore designation visible while the supplied NCMASTER UCFL data sheet remains the source for dimensions and bearing-unit details.
UCFL201 quick reference
Approximate listing reference only. Verify the supplied item and the complete machine design before final fitment.
UCFL pillow bearing reference sheet
Select the image for the full-size source reference. The image is supporting information; confirm the supplied part before ordering or installation.
Exact public title verified from the official NCMASTER UCFLXX Pillow Metal Casted Bearing category. The local UCFL data sheet is the dimensional and bearing-unit reference; confirm the supplied unit and shaft fit before publication.
Selection and use
- Match the UCFL bearing bore to the round shaft diameter. Confirm the two-hole flanged mounting arrangement, shaft fit and supplied unit before installation.
- Use the matching guide, shaft or carriage components shown by the family reference.
- Keep the mounting surface aligned and suitably supported for the intended application.
Included in this draft listing
1 x UCFL201 - 12mm Pillow Casted Metal Bearing Block
Package quantity and any separately supplied matching components must be confirmed against the live product record before publication.
